With over 550 employees worldwide, Prüftechnik are world leaders in Condition Based Monitoring, Non-Destructive Testing and Laser Alignment solutions across a wide range of industrial applications.

With products, processes and services for condition monitoring and availability optimization, Prüftechnik helps to ensure that your machines run smoothly and generate an output of consistently high quality. This also includes systems for automatic process control and quality assurance that are integrated directly in your production process.



PERMABLOC shims are up to 400% more cost-effective than hand-cut shims. PERMABLOC shims both reduce labour cost during installation and repair, and assist inventory control.

PERMABLOC also helps avoid risk of injury when the sharp-edged shims are cut and inserted.

  • Bur-free for higher accuracy in machinery alignment
  • Four machine foot sizes, eight thicknesses
  • Corrosion-resistant high-quality stainless steel
  • Time-saving permanent thickness / dimension marking
  • No 'leaf spring' effect from stacked shims: only 3 shims are enough!
  • Perfectly flat for stable, consistent machine support
  • Perforated tab for easier positioning and removal​

PERMABLOC® precut shims have been widely used in industry for more than 20 years. They eliminate the time consuming search for material, and bespoke cutting to size. Shims are available in 5 machine foot sizes with 8 thicknesses in each size range which meets most shim correction requirements whilst using a maximum of just three shims per machine foot.​

PERMABLOC® precut shims

  • are available in 5 different sizes and a range of thicknesses that fit almost all machine feet
  • are made of high-quality stainless steel (1.4301 and 1.4310) and thus offer long-term resistance against corrosion, acids and lyes
  • come in a graded range of thicknesses that allows you to put together virtually all heights from 0.1 to 3 millimetres with just 3 shims, thus avoiding dangerous vibration under the machine feet
  • are fully deburred and perfectly flat to ensure stable and consistent machine support over their entire surface
  • come with permanent size and thickness marking
  • are deburred and have rounded corners and edges to minimise the risk of injury
  • minimise the risk of injury
  • have a perforated tab for easier positioning and removal
  • come in a range of cases, each containing a complete assortment of shims
  • are reusable
  • have a longitudinal shape for optimum support of the machine foot without material overhang

Shims are available in individual packs of 20 pieces per thickness or better still are supplied as shim kits packed in a rugged case to facilitate access and transportation to site.


PERMABLOC® professional case sizes


The advantages of the case at a glance

  • Considerably lighter than a sheet steel case
  • More robust than conventional cases
  • Type of protection IP 67 (dustproof and can be immersed in water)
  • Clear arrangement of the shims
  • Clear thickness labelling
  • Plenty of room for additional shims even with standard contents
